Intelligent Vertical Carton Erector GCE-45
Category Carton Erector
GCE-45 Intelligent Vertical Case Erector is equipped with servo intelligent control system, which automatically completes box suction, carton forming, bottom folding and tape sealing. It delivers high-precision square forming and is compatible with soft, hard and slightly wrinkled cartons. The vertical magazine supports carton replenishment without shutdown. It features convenient size changeover via touch-screen and stable operation. It can run standalone or connect to automatic packaging lines, suitable for intelligent packaging production in e-commerce, food, pharmaceutical and other industries.
Specification
Specification
| Machine Model | GCE-45 |
| Carton Opening Speed | 10-30ctns/min |
| Carton Size | L200-500 *W150-400 *H100-400mm |
| Power Supply | 380V 50Hz |
| Power | 5000W |
| Adhesive Tape Width | 55-72mm |
| Air pressure | 6~8Kg/cm³ |
| Air Consumption | 400L/min |
| Equipment weight | 1400kg |
| Table Height | 620-650mm |
| Machine Size | L2240*W2680*H1900mm |
