CornerEdge Tape Carton Sealer GPB-56+GPG-755E
Category Carton sealer
The corner-edge tape tape tapeCarton Sealer GPB-56 + GPG-755E is applicable to various carton specifications. It only requires manual adjustment of width and height, which is convenient and fast. Equipped with a 90° corner transfer machine and an air cylinder for automatic carton pushing, it can automatically seal, flatten, and process the four upper and lower corners of cartons simultaneously in a fast and stable manner. It can also be combined with GPA/GPB/GPC models to form a complete H-shaped carton sealing system.
Specification
Specification
| Machine Model | GPB-56 | GPG-755E |
| Conveyor speed | 18m/min | 6-8PCS/min |
| Carton Size | L150-∞×W180-500×H150-600mm | L320-700mm×W200-500mm×H180-500mm |
| Power Supply | 220V 50/60Hz 1Phase | 220V 50/60Hz 1Phase |
| Power | 240W | 1020W |
| Adhesive Tape Width | 55-72mm | 60-72mm |
| Air Consumption | / | 220NL/min |
| Air Compressing | / | 0.6Mpa |
| Table Height | 600~750mm | 600-650mm |
| Machine Size | L1020×W850×H450mm | L1920×W1330×H1520mm |
| Machine Weight | 150kg | 450kg |
