Automatic Flap-Folding Carton Sealing with Automatic Four-Corner Carton Sealing GPC-50+GPG-755E
Category Carton sealer
GPC-50 + GPG-755E is a combined system of an automatic flap-folding carton sealer and an automatic four-corner edge carton sealer, forming an automatic “H”-shaped carton sealing process. It can automatically fold the top flaps, convey cartons, perform top and bottom “I”-shaped sealing, and use auxiliary wheels on both sides to assist in sealing, ensuring that the adhesive tape is not misaligned. Immediately afterward, the cartons are pushed through an L-shaped corner and conveyed to the four-corner edge sealing station for operation. This system is simple and practical, and is widely used in industries such as food, medicine, beverages, tobacco, and daily chemicals.
Specification
Specification
| Machine Model | GPC-50 | GPG-755E |
| Conveyor speed | 18m/min | 6-8PCS/min |
| Carton Size | L200-600×W150-500×H150-500mm | L320-700mm×W200-500mm×H180-500mm |
| Power Supply | 220V 50/60Hz 1Phase | 220V 50/60Hz 1Phase |
| Power | 420W | 1020W |
| Adhesive Tape Width | 55-72mm | 60-72mm |
| Air Consumption | 50NL/min | 220NL/min |
| Air Compressing | 0.6Mpa | 0.6Mpa |
| Table Height | 600-750mm | 600-650mm |
| Machine Size | L1770×W920×H1520mm | L1920×W1330×H1520mm |
| Machine Weight | 270kg | 450kg |
