Automatic Corner-Edge Carton Sealer GPH-655
Category Carton sealer
Automatic Corner-Edge Carton Sealer GPH-655: After the middle line of the carton is sealed into an “I” shape by the front-end “I”-shaped carton sealer, the carton is pushed through an L-shaped corner and conveyed to undergo four-corner edge sealing operations. It features intelligent adjustment of carton sizes, with photoelectric eyes for automatic sensing, air cylinders for automatic positioning, and upper and lower driving belts for automatic calibration and conveying of cartons. The sealing process is fast and stable, with folded corners free of wrinkles, making it suitable for various types of cartons. This carton sealer is widely used in industries such as food, medicine, beverages, daily chemicals, and electronics.
Specification
Specification
| Machine Model | GPH-655 |
| Packing speed | 4-6PCS/min |
| Carton Size | L320-600mm×W200-500mm×H180-500mm |
| Power Supply | 220V 50/60Hz 1Phase |
| Power | 1020W |
| Adhesive Tape Width | 60-72mm |
| Air Consumption | 450NL/min |
| Air Compressing | 0.6Mpa |
| Table Height | 600-650mm |
| Machine Size | L2120×W1350×H1580mm |
| Machine Weight | 450kg |
